Key Features

Constant 1,000 fps

Continuous recording at 1,000 fps with no compression or frame skipping.

High Quality Raw Files

Video format is raw 10 or 12 bit standard DNG (Digital Negative) format.

Long Record Time

A generous 256GBytes of high speed video memory for 2 full minutes of recording time.

Small, Light, Portable

Integrated batteries and touch LCD provide ultimate portability and versatility.

The Revolution is here

High frame rate cameras are traditionally large, expensive, bulky and very restricted in record times. It makes sense – to produce 1,000 frames / second you need very fast video rates – 10, 20, 40 GBits/second or more and large amounts of memory – over 1 GByte for every second recorded. Then you need a large power supply to drive all this. But this all changes with the fps1000 which incorporates the latest in processing and memory technology to dramatically reduce the cost and form factor of high frame rate cameras.

Small, Light, Portable

The fps1000 is small and light enough to be handheld. It does not need a host computer to operate. You can live preview, record and playback all using the built in 5 inch LCD touch screen. Internal batteries power the camera for typically 1-2 hours. This is the most portable high frame rate camera in its class.

Large Memory, Long Record Time

The fps1000 has an incredible 256GBytes of internal memory as standard. This is enough for two full minutes of full speed image capture. You no longer have to carefully plan each shot and set up triggers to capture the crucial few seconds. This is point and shoot adding a huge range of new opportunities. The memory is also non-volatile so you can save the images in camera for as long as you want even with the power off.

Highest Quality Raw Files

All videos from the fps1000 are saved as raw files in industry standard DNG format. Read them into your favourite post processing application such as Lightroom or Final Cut Pro. Raw files retain all of the original image data in 12 bit colour depth so you retain maximum quality.

fps1000 Range

Features

  • Pixel size (microns)
  • Responsivity (V/Lux.s)
  • Frame Rate @ 1280 x 720
  • Frame Rate @ 640 x 360
  • Pixel Colour Depth
  • Global Shutter
  • Video Bandwidth
  • Video Memory Capacity
  • Recording Time At Max Frame Rate
  • Maximum Resolution
  • Sensor Format
  • Frame Rate Adjustment
  • Exposure Adjustment
  • IR Cut FIlter
  • Integral Disk
  • Computer Interface
  • Touch LCD Screen
  • Lens Mount
  • Tripod Mount
  • External Power Input
  • Batteries (Not Supplied)
  • Cooling
  • Trigger In
  • Genlock
  • Trigger Out
  • Output File Format
  • Dimensions (excluding lens) mm
  • Approximate Weight (excluding Lens)
  • Supplied Lens

fps1000HD-256

£1,899
  • 6.6
  • 9.6
  • 1,000 fps
  • 4,000 fps
  • 12 bits
  • 12 GBits / sec
  • 256 GBytes
  • 120 seconds
  • 1280 x 720
  • 2/3"
  • Fitted (easily removable)
  • Micro SD card
  • USB3
  • 5" Capacitive
  • C Mount Stainless Steel
  • 1/4” 20 Standard Mount
  • 7-12v 3Amps
  • 2 x 18650 Li ion
  • Active Cooled
  • Multi-function
  • Adobe DNG raw
  • 142 x 103 x 43
  • 700g
  • 35mm f1.7

fps1000HD-64

£1,599
  • 6.6
  • 9.6
  • 750 fps
  • 3,500 fps
  • 12 bits
  • 9 GBits / sec
  • 64 GBytes
  • 60 seconds
  • 1280 x 720
  • 2/3"
  • Fitted (easily removable)
  • Micro SD card
  • USB3
  • 5" Capacitive
  • C Mount Stainless Steel
  • 1/4” 20 Standard Mount
  • 7-12v 3Amps
  • 2 x 18650 Li ion
  • Active Cooled
  • Multi-function
  • Adobe DNG raw
  • 142 x 103 x 43
  • 700g
  • 35mm f1.7
Gallery
Contact Us

Join the revolution in slow motion camera technology

The fps1000, the low cost high speed camera
